LiDAR & Radar Sensor

Product Details:

Features:

• Equipped with RCWL-9196 chip supporting 4-28V wide voltage input, high level signal output when detecting the motion with active repeat trigger
• 360 degree no blind angle detection with 5-7m deteciting distance, the detection not affected by the surroundings, better performance than the IR sensor
• Support night detecting function turn on /off, adjustable repeat trigger time and detecting distance by add the SMD components to the corresponding pins
• Working Voltage: DC 4-28V, Board Size: 35.9 X 17.3mm/1.41 X 0.68inch

Adjustment Part Introduction:

• C-TM Adjust repeat trigger time,default trigger time is 2s;increasing capacitor''s capacity will make repeat trigger time longer;and actual counting trigger time can operate as below: Stick capacitor on C-TM,test 9196 3-pin frequency F,repeat trigger time T=(1/f)*32768

• R-GN Detection distance adjustment;connect with resistor and detection distance will become shorter;if not connect,detection distance is 7m;if connect with 1M ohm resistor,detection distance is 5m

• R-CDS Internal VCC parallel connect with internal 1M ohm resistor to CDS pin (that is 196 9-pin) by R-CDS ,CDS connects with photoresistor,you can close detection function at night

Pin Definition:

• 3V3:3V3 power output
• GND:ground
• OUT:control output;when detect moving objects,it will output high level
• VIN:input voltage,4-28V
• CDS:enable control chip,lower than 0.7V,OUT will output low level all the time

Additional Information:

• Packaging Details: RCWL-0516 Microwave Radar Sensor Switch Module x1

Product Details:

YDLIDAR G2 is a 360° 2D LiDAR(hereinafter referred to as G2) developedbyYDLIDAR team. Based on the principle of Triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 ° to continuously output theangle information as well as the point cloud data of the scanning environment while ranging.

Features:

• 360° scan ranging
• High accuracy, stable performance
• Wide measuring range
• Strong resistance to ambient light interference
• Industrial grade brushless motor drive, stable performance
• Class I eye safety
• 360° omnidirectional scanning and 5-12Hz frequency
• Using optical and magnetic fusion technology to realize wireless communication and wireless power supply
• High-speed ranging, up to 5000Hz frequency

Application:

• Robot navigation and obstacle avoidance
• Industrial automation
• Regional security
• Intelligent transportation
• Environmental scanning and 3D reconstruction
• Digital multimedia interaction
• Robot ROS teaching and research

Additional Information:

• Item Code: LiDAR-G2
• Delivery Time: 8 - 10 days

Product Details:

YDLIDAR X2 is a 360° 2D LiDAR(hereinafter referred to as X2) developed by YDLIDAR team. Based on the principle of Triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 ° to continuously output the angle information as well as the point cloud data of the scanning environment while ranging.

Features:

• 360° scan ranging
• High accuracy, stable performance
• Wide measuring range
• Strong resistance to ambient light interference
• Low power consumption, small size, stable performance and long life
• Class I eye safety
• Motor speed is adjustable, the proposed speed is 6Hz
• Ranging frequency up to 3KHz

Application:

• Robot navigation and obstacle avoidance
• Robot ROS teaching and research
• Regional security
• Environmental scanning and 3D reconstruction
• Navigation and obstacle avoidance of home service robots/sweeping robots

Additional Information:

• Item Code: LiDAR-X2

Product Details:

YDLIDAR X4 is a 360° 2D LiDAR(hereinafter referred to as X4) developed by YDLIDAR team. Based on the principle of Triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 ° to continuously output the angle information as well as the point cloud data of the scanning environment while ranging.

Features:

• 360° scan ranging
• High accuracy, stable performance
• Wide measuring range
• Strong resistance to ambient light interference
• Low power consumption, small size, stable performance and long life
• Class I eye safety
• Motor speed is adjustable, the proposed speed is 6~12Hz
• High-speed ranging, ranging frequency up to 5KHz

Applications:

• Robot navigation and obstacle avoidance
• Robot ROS teaching and research
• Regional security
• Environmental scanning and 3D reconstruction
• Navigation and obstacle avoidance of home service robots/sweeping robots

Additional Information:

• Item Code: LiDAR-X4

Product Details:

YDLIDAR G4 is a 360° 2D LiDAR(hereinafter referred to as G4) developedbyYDLIDAR team. Based on the principle of Triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360° to continuously output theangle information as well as the point cloud data of the scanning environment while ranging.

Features:

• 360° scan ranging
• High accuracy, stable performance
• Wide measuring range
• Strong resistance to ambient light interference
• Industrial grade brushless motor drive, stable performance
• Class I eye safety
• 360 ° omnidirectional scanning and 5-12Hz frequency
• Using optical and magnetic fusion technology to realize wireless communication and wireless power supply
• High-speed ranging, up to 9000Hz frequency

Applications:

• Robot navigation and obstacle avoidance
• Industrial automation
• Regional security
• Intelligent transportation
• Environmental scanning and 3D reconstruction
• Digital multimedia interaction
• Robot ROS teaching and research

Additional Information:

• Item Code: LiDAR-G4
• Delivery Time: 8 - 10 days

Product Details:

HLK-LD1115H Radar Sensor is a high sensitivity 24GHz millimeter wave human presence detection radar module. The main feature of this module is that on the basis of the function of the traditional human body induction radar, it also has the function of judging the existence of the human body by detecting and accumulating small movements such as human breathing. Therefore, the presence detection within a certain range has higher accuracy and is not easy to miss.

Additional Information:

• Item Code: LD1115H

Product Details:

24GHz millimeter wave radar sensor motion detection sensor PIR module LD112 low power consumption and small size

HLK-LD112-24G Internet of Things microwave radar module, which can be used to detect moving targets in a small range, and output high and low level information, and is not affected by the installation environment. It can automatically filter various debris (still life) in the environment, Such as tables, mops, etc.



HLK-LD112-24G has industry-leading excellent performance, small size, low cost, and low power consumption. It can provide customers with ideal and better performance object movement monitoring solutions.

24GHz millimeter wave radar sensor motion detection sensor PIR module LD112 low power consumption and small size

Additional Information:

• Item Code: hlk-ld112-radar-sensor

Product Details:

24GHz millimeter wave radar sensor PIR motion monitoring module LD116 small size, low power consumption, wide detection

HLK-LD116-24G IoT millimeter wave radar module, which can be used to detect moving targets in a small range, and output high and low level information, and is not affected by temperature, humidity, airflow, dust, noise, brightness, etc., anti-interference Strong ability to penetrate acrylic, glass, plastic and other thin non-metal materials. HLK-LD116-24G has industry-leading excellent performance, small size, low cost, and low power consumption. It can provide customers with ideal and better performance object movement monitoring solutions.



Additional Information:

• Item Code: hlk-ld116-radar-sensor

Product Details:

HLK-LD1125H-24G Radar Sensor is a high sensitivity 24GHz millimeter wave human presence detection radar module. The main feature of this module is to judge the existence of the human body by detecting and accumulating tiny movements such as human respiration. Therefore, the detection of human presence is more accurate than traditional mobile detection radars. Not easy to miss

Additional Information:

• Item Code: hlk-ld112h-radar-sensor

Product Details:

LD2410 is a high-sensitivity 24GHz human presence status sensing moduledeveloped by Hi-link. Its working principle is to use FMCW frequency-modulated continuous waves to detect human targets in the set space. Combined with radar signal processing and precise human body sensing algorithms, it realizes high-sensitivity human presence status sensing, and can identify human bodies in motion and stationary states. And auxiliary information such as the distance of the target can be calculated.

This product is mainly used in indoor scenes to sense whether there is a moving or micro-moving human body in the area, and output the detection results in real time. The farthest sensing distance can reach 5 meters, and the distance resolution is 0.75m. Provides a visual configuration tool, which can easily configure the sensing distance range, sensing sensitivity in different intervals and unmanned delay time, etc., to adapt to different specific application needs.

Support GPIO and UART output, plug and play, and can be flexibly applied to different smart scenarios and terminal products.

Additional Information:

• Item Code: hlk-ld2410B
